- Place of Origin: Zhaoqing Guangdong
- Brand Name: SALOON
- Model Number: SL-2016A
SL-2016A 全自动电脑切捆条机 Computerized Fully-automatic Strip Cutter
●Technical parameter:
Band width: from 5mm to 1680mm
Maximum operation width:2200mm
Output each workday:2000m~6000m(10mm~35mm)
Maximum roll diameter:Φ280 mm
Blade diameter:Φ400mm
Power :220V/380V, Single phase/ Three phase
Machine dimension(L×W×H):30000×1250×1400mm
●Mierocomputer programmed data input,visual interface for operation
and easy & comfortable start-up.
Progratiamed data control,step motor drive,accurate size for the needs,
five different sizes of cutting Off the same cloth beam;once the machine
is started,it can complete cutting on once a time.
Magic eye for the monitoring of cutting,electronically-tuned cutting rate,elecironic
transduction for the printipal axis of cutter.
Magic eye for the monitoring,manilal or automatic kinfe sharpener and sharpener;
the time for pause can be set and the sharpeners can work simultaneously.
Chinese & English operating interface,which is suitable for many languages;
it is simple and understandable for ordinary workers.
Vacuum unit to remove excess trimmed material and sharpening dust.
Pneumatic fabric loading support.
Automatic chuck,raise work efficiency of 35%.
